Swing Clamp with Various Swing Angles

Swing angle of standard swing clamp can be selected
from 0°, 30°, 45°, 60°, 90°.
We also provide custom swing angle of 180°.
Please contact us for other swing angles.

High-Power Side Clamp

Compact side clamp with a built-in high-power function saves space for a fixture.

Custom Link Clamp

At released state, the lever rotates 180° in order to
prevent interference with a machining tool or
a loading robot hand.

2-Position Clamp

The 2-position clamp allows for two different workpieces by controlling clamping points.
There is no need to change a fixture for different workpieces.

Support Hole Clamp

Custom clamp with functions of hole clamp and work
support enables clamping of workpiece hole that is not a
seating reference part.
At released state, seating surface of the clamp goes down along a workpiece touched by spring advance.
At locked state, the seating surface is held at the position,
and the gripper clamps the workpiece.

Locating Hole Clamp

Custom clamp with functions of hole clamp and locating pin enables unification of clamping hole and locating hole.

Palm Tree Clamp
(Two-side Pulling Clamp)

Clamping part is retracted in a cylinder at released state.
When locked, the clamping part comes out to clamp from
upper side of the clamping point.
Best used for clamping an upper surface of a workpiece
hole or uneven surfaces inside a workpiece hole.

Rodless Hollow Chucking Cylinder

The cylinder clamps an outer surface of a workpiece.
Used for clamping a workpiece during transfer or operation with a robot.

Large Expansion Locating Cylinder

Locating pin with large expansion stroke.
Allows for different workpiece hole diameters.

Expansion Locating Cylinder for Large Diameter

Expansion locating pin to locate a large diameter workpiece hole.
Inner diameter of workpiece hole in this video: φ220

Bore Locating Cylinder

The cylinder uses holes of 4-cylinder engine block for locating.

Crab Scissors Clamp
(Pulling Cylinder for Cylindrical Workpiece)

Pulling cylinder (hand) to transfer a cylindrical workpiece.
