Auto Fixture Changeover for Deburring Process

Automatic fixture pallet changeover with High-Power
Pneumatic Pallet Clamp enables application for a variety
of workpieces. After setting a pallet with a robot,
the pallet clamp secures clamping and locating at once.
With high locating repeatability 3μm, it enables high-
quality machining, reduces errors, and prevents
accidents and machine stops caused by locating failures.

Workpiece Loading to Machine with Hole Clamp

Automatic workpiece loading example with gantry loader.
High-power Pneumatic Hole Clamp enables a compact
transfer hand by clamping workpiece holes.
The contamination-resistant clamp is suitable for
machining workpieces with machine tools. Safe workpiece
transfer is possible by self-locking with a built-in
spring even when air pressure is accidentally cut off.

Moment-Resistible Gripper for Pallet Transfer

Pallet Gripper for pallet transfer simplifies fixture setup
and saves space of pallet stocker by approaching from
the side.

Unlike other standard transfer hands, Pallet Gripper
withstands high moment and suitable for pallet transfer.

Tapped Hole Testing Process Automation

Workpiece Testing Automation Example with Robot
Tool change of tapped hole auto-testing device and
plug gauge with zero-backlash and high locating
repeatability Robot Hand Changer. Auto testing of
several workpieces with a robot is also possible by
changing tools of additional gauges and air micro
meters, etc.

"Add High-Accuracy Locating" to Robot and Cart

With Kosmek FA＆Industrial Robot Related Products,
we can connect manual carts and AGVs with robots
by "Mechanical Locking".
Pallet Clamp connects a transferred robot to a working
station with robot and fixture with 3μm accuracy.
NO NEED of re-positioning with a camera or others,
saving time and costs for correcting devices.

Solution with Welding Clamp and Tool Stocker

Having trouble with frequent application stops caused
by loading and locating failure during automatic transfer
of welding workpieces?
KOSMEK welding product: Locating Pin Clamp reduces
such risks with high performance.
Also, High-Power Pull Stud Clamp saves space for tools
by setting a tool stocker above the robot.
